EC technology fans: Innovation in industrial ventilation
EC technology of ECOFIT ventilation solutions
- Code :
- Q38-A3
- Designation :
- GREV8 180x75R
- Voltage :
- 230V (50/50/60Hz)
- Code :
- X52-A0
- Designation :
- RREG9 220x43R
- Voltage :
- 230V (50/60Hz)
- Code :
- A23-L6
- Designation :
- RRMF5 192x40R
- Voltage :
- 230V (50/60Hz)
- Code :
- X52-A2
- Designation :
- RREG9 192x40R
- Voltage :
- 230V (50/60Hz)
- Code :
- P38-D1
- Designation :
- RREV8 280x50R
- Voltage :
- 230V (50/60Hz)
- Code :
- Y07-A4
- Designation :
- RREuF5 175x42R
- Voltage :
- 120V (50/60Hz)
- Code :
- Z41-E1
- Designation :
- GREuG9 160x62R
- Voltage :
- 120V (50/60Hz)
- Code :
- Q37-C9
- Designation :
- GDSV8 160x160L
- Voltage :
- 230V (50/60Hz)
- Code :
- P38-A8
- Designation :
- VGRV8 350A
- Voltage :
- 230V (50/60Hz)
EC ECOFIT motors and fans combine high efficiency, low consumption, and built-in intelligence. Manufactured in France and compliant with the ErP directive, they guarantee performance, quietness, and durability for all your ventilation applications.
What is EC technology?
EC motors are synchronous permanent magnet motors controlled by intelligent electronics. Unlike traditional AC asynchronous motors, current switching is managed electronically by an integrated microcontroller, eliminating efficiency losses due to slip and ensuring maximum efficiency across the entire speed range.
Thanks to this design, ECOFIT EC motors achieve better efficiency, resulting in energy savings compared to conventional AC solutions.
How the ECOFIT EC motor works
ECOFIT EC motors combine performance and intelligence:
- Permanent magnet rotor.
- Stator controlled by a microcontroller via electronic switching.
- Universal power supply: 230V 50/60Hz or 120V 50/60Hz.
- Precise control via 0–10V signal, PWM, or specific software (constant flow, constant pressure, etc.).
This technology offers high motor torque, speed control, and increased longevity thanks to the absence of brushes.
French innovation and ErP compliance
EC ECOFIT motors are entirely designed and manufactured in our factory in Vendôme (France).
Our expertise and measuring equipment enable us to guarantee that our fans comply with the European ErP Directive (2009/125/EG) – Energy related Products.
This directive sets energy efficiency requirements for energy-consuming products.
Advantages of ECOFIT EC technology
EC ECOFIT motors represent the new generation of low-consumption motors:
Efficiency and performance
- Superior efficiency.
- Lower power consumption than an AC motor.
- Constant torque and stable performance across the entire speed range.
Safety and reliability
- Integrated monitoring functions: motor temperature, rotor lock, overload, etc.
- Advanced electronic protection for safe and durable operation.
Ease of integration
- Plug & Play systems.
- Continuous speed variation (0–10V, PWM).
- Tachometer output and integrated alarm option.
- Dedicated software for constant flow or constant pressure without a sensor.
Versatility and durability
- Compact design
- Can be used worldwide thanks to its voltage and frequency compatibility and regulatory compliance.
- Significant reduction in carbon footprint and operating costs.
Quiet, reliable, and smart
EC ECOFIT motors also stand out for their quiet, maintenance-free operation.
The integrated electronics of EC technology enable intelligent control, ensuring precise regulation and real-time monitoring of fan operation.
This automatic monitoring guarantees optimal operation and maximum service life for the devices.
EC ECOFIT motors
There are three categories based on the maximum power required:
- F5 motors up to 85 W
- G9 motors up to 170 W
- V8 motors up to 300 W
EC ECOFIT fans
EC motors are integrated into the following ranges:
- Backward fans: diameters from 133 to 315 mm.
- Single inlet foward fans: diameters from 120 to 180 mm, with constant flow or constant pressure options without sensor.
- Double inlet forward fans: diameters from 120 to 180 mm, same smart control options.
- Axial fans: diameters from 200 to 400 mm.
